產品特色

• 超快速 WiFi 7：新一代 WiFi 7 路由器可將速度提升至 3600 Mbps。
• 4K-QAM 調變：全新 4096-QAM 的傳輸速度比上一代提升 1.2 倍。
• 高運算能力 CPU：配備全新的 Broadcom 四核心強大 CPU，擁有 20K 的 DMIPS 運算能力，可輕鬆處理軟硬體相關工作。
• 支援可擴充功能 ：運用獨家 AiMesh 技術可彈性擴充設備，打造全屋無縫網路。
• 通過測試的耐用性和穩定運作：TUF Gaming BE3600 極為耐用並通過多項驗證測試，以確保可靠穩定的運作。

產品規格

• 型號TUF Gaming BE3600 (TUF-BE3600)

網路技術標準

• IEEE 802.11a
• IEEE 802.11b
• IEEE 802.11g
• WiFi 4 (802.11n)
• WiFi 5 (802.11ac)
• WiFi 6 (802.11ax)
• WiFi 7 (802.11be)
• IPv4
• IPv6

產品規格

• BE3600 ultimate BE performance : 688+2882 Mbps

傳輸量

• 802.11a：最高 54 Mbps
• 802.11b：最高 11 Mbps
• 802.11g：最高 54 Mbps
• WiFi 7 (802.11be) (2.4GHz): up to 688 Mbps
• WiFi 7 (802.11be) (5GHz): up to 2882 Mbps

天線

• External antenna x 4

傳送 / 接收

• 2.4GHz 2x2
• 5GHz 2x2

處理器

• 2.0 GHz quad-core processor

記憶體

• 256 MB Flash
• 1 GB RAM

網速提升

• OFDMA (Orthogonal Frequency Division Multiple Access)
• Beamforming: standard-based and universal
• 4096-QAM high data rate
• 20/40/80/160 MHz bandwidth

運作頻率

• 2.4GHz / 5GHz
• 2.4 GHz
• 5 GHz

Operating Mode

• Wireless router mode
• Access point mode
• Media bridge mode

網路埠規格

• RJ45 for 2.5 Gigabits BaseT for WAN x 1,
• RJ45 for Gigabits BaseT for LAN x 4,
• USB 3.2 Gen 1 x 1,

按鈕

• WPS Button, Reset Button, Power Button

LED 指示燈

• Power x 1
• WAN x 1
• LAN x 1
• 2.4GHz WiFi x 1
• 5GHz WiFi x 1

電源規格

• AC Input : 100V~240V (50~60Hz)
• DC Output : 12 V with max. 2 A current

包裝內容物

• TUF Gaming BE3600 Dual Band WiFi 7 router
• RJ-45 cable
• Power adapter
• Quick Start Guide
• Warranty card

產品淨重(g)

• 561g

Product Dimensions

• 274 x 168 x 205 mm

獨家AiMesh技術

• AiMesh
• Primary AiMesh router
• AiMesh node

遊戲加速

• 有Mobile Game Mode

家長貼心管理

• Parental Control
• Safe Browsing
• Parental Control Customized Internet schedule

Guest Network

• Guest Network
• • Maximum Guest Network Rule : 2.4GHz x3, 5GHz x3

Security

• AiProtection
• WPS support, WPA/WPA2/WPA3-Personal, WPA/WPA2-Enterprise
• WPS
• Let's Encrypt
• DNS-over-TLS
• SSH
• Security Scan
• Firewall
• • Maximum Firewall Keyword Filter : 64
• • Maximum Firewall Network Service Filter : 32
• • Maximum Firewall URL Filter : 64

AiProtection

• AiProtection
• Malicious site blocking
• Two-Way IPS
• Infected Device Prevention and Blocking

VPN

• VPN Client L2TP
• VPN Client OVPN
• VPN Client PPTP
• VPN Client WireGuard
• VPN Server IPSec
• VPN Server OVPN
• VPN Server PPTP
• VPN Server WireGuard
• VPN Fusion

網路流量控制

• Adaptive QoS
• Bandwidth Monitor
• Bandwidth limiter
• -- Maximum Bandwidth Limiter Rule : 32
• Traditional QoS
• -- Maximum Traditional QoS Rule : 32
• Traffic Monitor
• Real-time traffic monitor
• Wired Traffic Monitor
• Wireless Traffic Monitor
• Traffic Analyzer
• • Traffic Analysis Period : Daily, Weekly, Monthly
• Website history

WAN

• Internet connection Type : PPPoE, PPTP, L2TP, Automatic IP, Static IP
• WAN Aggregation
• 3G/4G LTE dongle
• Port forwarding
• • Maximum Port Forwarding Rule : 64
• Port triggering
• • Maximum Port Triggering Rule : 32
• DMZ
• DDNS
• NAT Passthrough : PPTP Pass-Through, L2TP Pass-Through, IPSec Pass-Through, RTSP Pass-Through, H.323 Pass-Through, SIP Pass-Through, PPPoE relay

LAN

• DHCP Server
• 有
• IPTV
• LAN Link Aggregation
• Manually assign IP address
• • Maximum Manually Assign IP Address Rule : 64
• Wake on LAN (WOL)

其他無線功能

• UTF-8 SSID
• WiFi MAC address filter
• • Maximum MAC Filters : 64
• Wireless scheduler
• Airtime fairness
• RADIUS Server
• Universal beamforming
• Explicit beamforming

USB埠應用

• File System : HFS+, NTFS, vFAT, ext2, ext3, ext4
• Safely Remove disk
• AiCloud
• Download master
• AiDisk
• Media Server
• Time Machine
• Samba Server
• FTP Server
• Shared Folder privileges

管理功能

• Configuration backup and restore
• Diagnosis tools
• Feedback system
• System log
• New Device Connect Notification
• Login Captcha
• Connection Diagnosis
• Auto Firmware Update
